Key Specifications

Family

Classic Series 240V

Line Voltage

240 Volts

Power Requirements

240 Volts

Number of Outlets

11

Number of Isolated Banks

2

Outlet Description

All 11 outlets linearly filtered and surge protected

Rack Mountable

Yes

Rack Ears Included

Yes

Front Panel Meters

No

Front Media Lights

2 Multi-LED, Dimmable Lamps

Control

On/Off Switch and Light Dimmer Knob (Front Panel)

Voltage Regulation

N/A

Compliance

CE

Dimensions (W × D × H)

482.6 × 266.7 × 44.5 mm

Power Consumption

12 Watts

AC Protection

Extreme Voltage Shutdown
Series Multi-Stage Protection
Non-Sacrificial Protection with Zero Ground Contamination

Under-Voltage Shutoff

180 V

Over-Voltage Shutoff

274 V

Maximum Current Rating

10 Amps

Initial Clamping Level

375 VAC Peak @ 3,000 Amps

Filtration Technology

LiFT

Filtration Rating

10 dB @ 10 kHz
40 dB @ 100 kHz
50 dB @ 500 kHz

Power Cord

3/1.0 mm² AWG, 2.5 m Cord with IEC Female to 10A Schuko Plug

Voltage Protection Rating

UL 1449 3rd Edition, 3,000 A

Response Time

1 Nanosecond

Peak Impulse Current

6,500 Amps

Rear BNC Connector

Rear Rack Lamp, 12 VAC 500 mA Max (Lamp Not Included)

UPC

654061028093
