Key Specifications

Frequency Response (-10 dB)

100 Hz - 20000 Hz

Max SPL @ 1m

98 dB

Coverage Angle

150°

System Sensitivity

90 dB

Power Section

Power Handling

6 W RMS / 24 W PEAK

Recommended Amplifiers

DMA 504, DMA 162, DMA 82, AM 2080, UP 2162 (and similar 100V amps)

Transducers

1 x 6.0'' Fullrange (Dual-cone)

Input / Output Section

Constant Voltage Transformer

100 V

Power Selection (Taps)

6 W (1667 Ω), 3 W (3333 Ω)

Connectors

Screw Terminals

Physical Specifications

Cabinet & Grille Material

Self-extinguishing Plastic (UL-94-H-B)

Color

White - RAL 9003

Dimensions (Dia x D)

186 x 65 mm / 7.32 x 2.56 inches

Recessed Depth

59 mm / 2.32 inches

Weight

0.5 kg / 1.1 lbs

Shipping Information

Package Height / Weight

80 mm (3.15") / 0.6 kg (1.32 lbs)
