RELACART PM-100D TX
RELACART PM-100D TX
|
Key Specifications |
|
|
Chassis Specification |
1U Half-Rack |
|
Carrier Frequency Range |
521.25MHz-936.85MHz |
|
Frequency Bandwidth |
32MHz (depending on the region) |
|
Modulation Method |
Integrated mode |
|
Output Power |
50mW |
|
Audio Performance |
|
|
Comprehensive Frequency Response |
20Hz-20KHz ±3dB |
|
Comprehensive T.H.D. |
<0.9%@1KHz |
|
Inputs & Outputs |
|
|
Audio Input |
XLR and Φ6.3mm composite socket |
|
Audio Output |
Φ6.3mm balanced socket × 2 |
|
Power Supply |
|
|
Power Supply Mode |
DC 12V |
|
Current Consumption |
160mA |
|
Dimensions & Weight |
|
|
Dimensions (mm) |
205 (W) × 43 (H) × 206 (D) |
|
Weight |
Approximately 1kg |
RELACART PM-100D TX Accessories
- No accessories available.
