Key Specifications

Product Type

Power Amplifier

Audio System

Functions

Amplifier

Amplifier Class

Class-D

Audio D/A Converter

24-bit / 48 kHz

Digital Sound Processor (DSP)

Yes

Audio Specifications

20 Hz – 20 kHz Frequency Response
102 dB SNR
0.4% THD

Amplification

Total Output Power

4000 W

Amplifier Output Details

8 × 450 W @ 2 Ω (THD 0.1%)
8 × 500 W @ 4 Ω (THD 0.1%)
8 × 300 W @ 8 Ω (THD 0.1%)
4 × 1000 W Bridged @ 2 Ω (THD 0.1%)
4 × 1000 W Bridged @ 4 Ω (THD 0.1%)
4 × 1000 W Bridged @ 8 Ω (THD 0.1%)
4 × 800 W Bridged (70 V, THD 1%)
4 × 1000 W Bridged (100 V, THD 1%)
2 × 1600 W Quad Bridged (70 V, THD 1%)
2 × 2000 W Quad Bridged (100 V, THD 1%)

Features

Thermal, short circuit, DC, over-current, over-voltage, and high-frequency protection
Supports 70V/100V or 2/4/8 Ω operation

Display

Display Type

Monochrome LCD Display

Connectivity

Connectors

8 × Balanced Audio Inputs (3-pin Phoenix)
8 × Speaker Outputs (Rear)
1 × USB Type-B (Front)
1 × RJ-45 Network (Rear)

Power

Voltage Required

AC 120/230 V (50/60 Hz)

Physical

Dimensions (W × D × H)

19 × 20.7 × 3.5 in

Weight

28.44 lbs

Shipping Weight

34.61 lbs

Box Dimensions (L × W × H)

27.5 × 22 × 8.3 in
