Key Specifications

Form Factor / Type

Rackmount

Number of Amplifier Channels

4

Amplifier Class

Class-D

Amplification

Load Impedance / Voltage Support

4 / 2 / 8 Ω

Power Rating per Channel

4 × 800 W (2 Ω)
4 × 600 W (8/4 Ω)
4 × 600 W (100/70 V)

Performance

Protections

RMS, Short Circuit, Thermal, Undervoltage

Frequency Response

20 Hz – 20 kHz

SNR / Noise

< 108 dBA

THD / Distortion

≤ 0.1% Distortion
≤ 0.1% THD+N

Crosstalk

-70 dB (Typical)

Signal Processing

A/D and D/A Conversion

24-bit / 192 kHz

DSP

24-bit DSP at 48 kHz

Audio Delay

Adjustable up to 100 ms

EQ & Filters

5-Band Parametric EQ, Crossover

Dynamics

Compressor, Limiter

Connectivity

Analog Audio I/O

1 × 8-pin block output

Digital Audio I/O

None

Network I/O

1 × RJ-45 Dante
1 × RJ-45 Ethernet

USB I/O

No

Phantom Power

No

Wireless

No

Power

Input Power

100 – 240 VAC, 50/60 Hz

AC Power Connector

1 × IEC 20 A

Current Consumption

20 A

Physical

Display

Single-LED indicators only

Rackmount Size

1U

Cooling

1 × Variable-speed fan

Operating Temperature Range

32 – 95°F / 0 – 35°C

Dimensions (W × D × H)

19 × 14.1 × 1.8 in (483 × 358 × 45 mm)

Weight

15.4 lb (7 kg)

Packaging Info

Package Weight

23.5 lb

Box Dimensions (L × W × H)

23 × 5 × 5 in
