Key Specifications

Number of Analog Input Channels

10 (4 Mono / 6 Stereo)

Number of Mic Preamps

4

Analog Output Channels

2x Stereo Master Output
1x Stereo Control Room/Monitor Output
1x Mono FX Send Output
1x Stereo Headphone Output

Mix Routing

1x Stereo Matrix Mix
1x Mono FX Send

EQ

3-Band EQ

Built-In Effects

24x Preset (Factory)

USB I/O

1x USB-B 2.0

Wireless

No

Rack Mountable

No

Mixer

Max I/O Capacity

10x Input / 3x Output

Number of Analog Input Channels

10 (4 Mono / 6 Stereo)

Number of Mic Preamps

4

Analog Output Channels

2x Stereo Master Output
1x Stereo Control Room/Monitor Output
1x Mono FX Send Output
1x Stereo Headphone Output

Mix Routing

1x Stereo Matrix Mix
1x Mono FX Send

Faders & Level Adjustment

No

Meters

Main Meter:
2x 12-Segment LED

Signal Processing

Dynamic Processing

Compressor

EQ

3-Band EQ

EQ Parameters

Low: ±15 dB at 80 Hz
Mid: ±15 dB at 2.5 kHz
High: ±15 dB at 12 kHz

Filters

High-Pass: 100 Hz, 18 dB/Octave

Solo/Mute

Mute per Input Channel

Built-In Effects

24x Preset (Factory)

Digital Audio

Bit Depth

24-Bit

Performance

Frequency Response

Mic Input to Output:
20 Hz to 30 kHz +0/-1 dB (Unity Gain)

Max Input Level

+22 dB

I/O Impedance

Mic Input:
3.3 Kilohms

Insert Return:
10 Kilohms

Line Input:
≥ 20 Kilohms

Headphone Output:
25 Ohms

Main Output:
120 Ohms (Unbalanced)
240 Ohms (Balanced)

Noise Floor

All Outputs:
-95 dBu (Master Level at -∞, Channel Levels at -∞)
-80 dBu (Master Level at Unity, One Channel Level at Unity)

THD+N

Mic Input to Main Output:
< 0.03% (+4 dBu)

Connectivity

Analog Inputs

2x Combo XLR-1/4" Balanced Mic/Line Input
2x XLR Balanced Mic Input
2x 1/4" TRS Unbalanced Hi-Z Input
4x 1/4" Balanced/Unbalanced Stereo Line Input (2 Stereo Pair)
1x 1/8" / 3.5 mm Stereo Aux Input
4x 1/4" FX Insert
1x 1/4" Footswitch

Analog Outputs

2x XLR 3-Pin Balanced Stereo Main Output (1 Stereo Pair)
2x 1/4" Unbalanced Stereo Main Output (1 Stereo Pair)
2x 1/4" Stereo Control Room Output (1 Stereo Pair)
1x 1/4" FX Send
1x 1/4" Headphone Output

Phantom Power

+48 V, Selectable On/Off (Applied to All Inputs)

Digital I/O

No

MIDI I/O

No

USB I/O

1x USB-B 2.0

USB I/O Capacity

2x Input / 4x Output

Wireless

No

Compatibility

OS Compatibility

Windows / macOS

Power

AC Input Power

Universal:
100 to 240 VAC, 50 / 60 Hz

Power Supply Output

12 VDC at 2 A

Physical

Rack Mountable

No

Dimensions

3.2 x 10.7 x 11.9" / 8.1 x 27.1 x 30.2 cm

Weight

4.9 lb / 2.2 kg

Packaging Info

Package Weight

6.635 lb

Box Dimensions (LxWxH)

15.1 x 12.8 x 4.3'
