Key Specifications

Mixer & I/O Capacity

Max I/O Capacity

22x Input / 3x Output

Analog Input Channels (Total)

22 (14 Mono / 8 Stereo)

Number of Mic Preamps

17

Mix Routing

1x Main Mix | 2x Bus/Subgroup

Faders

18x Channel Fader | 1x FX Fader | 2x Bus/Subgroup Fader | 1x Master Fader

Analog Outputs (Breakdown)

Master & Monitor

2x Stereo Master Output | 1x Stereo Control Room/Monitor Output

Bus & Aux

2x Stereo Bus/Subgroup Output | 3x Mono Aux Send Output | 1x Mono FX Send Output

Headphone

1x Stereo Headphone Output

Signal Processing & Effects

EQ

3-Band EQ (Low: 80 Hz, Mid: 100 Hz to 8 kHz, High: 12 kHz)

Filters

High-Pass: 100 Hz, 18 dB/Octave

Dynamics / Controls

Compressor (Input Channels) | Solo, Mute per Input Channel

Built-In Effects

24x Preset (Factory)

Digital Audio & USB

USB I/O Type / Capacity

1x USB-B 2.0 | 2x Input / 4x Output

Sample Rate / Bit Depth

Up to 192 kHz / 24-Bit

Compatibility

Windows / macOS / Linux

Connectivity Ports (Analog)

Mic Inputs

2x Combo XLR-1/4" | 12x XLR 3-Pin

Line Inputs

12x 1/4" Line | 6x 1/4" Stereo (3 Pairs)

Other Analog I/O

14x 1/4" FX Insert | 1x 1/4" Footswitch Input

Phantom Power

+48 V, Selectable On/Off (Applied to All Mic Inputs)

Performance (Key Metrics)

Frequency Response (Mic to Out)

20 Hz to 30 kHz +0/-1 dB (Unity Gain)

THD+N (Mic to Main Out)

< 0.01% (+4 dBu)

Noise Floor (Master Unity, One Channel)

-85 dBu

Physical & Power

Dimensions (H x W x D)

4.3 x 24.1 x 17.1" / 10.9 x 61.2 x 43.4 cm

Weight

19.8 lb / 9 kg

Power

Universal: 100 to 240 VAC, 50 / 60 Hz
