Key Specification

Model

PROFX6V3

Number of Analog Input Channels

6 (2 Mono / 4 Stereo)

Number of Mic Preamps

2

Analog Output Channels

2× Stereo Master Output
1× Stereo Headphone Output

Mix Routing

1× Stereo Main Mix
1× Stereo Insert

EQ

Mono Channels: 2-Band EQ
Low: ±15 dB at 80 Hz
High: ±15 dB at 12 kHz

Filters

High-Pass: 100 Hz, 18 dB/Octave

Built-In Effects

24 Preset (Factory)

USB I/O

1× USB-B 2.0 (2x Input / 4x Output)

Frequency Response

Mic Input to Output: 20 Hz – 30 kHz +0/-1 dB (Unity Gain)

Max Input Level

+22 dB

I/O Impedance

Mic Input: 3.8 kΩ
Insert Return: 10 kΩ
Line Input: ≥ 20 kΩ
Headphone Out: 25 Ω
Main Output: 120 Ω (Unbalanced), 240 Ω (Balanced)

Noise Floor

-95 dBu (Master Level -∞, Channel Levels -∞)
-80 dBu (Master Unity, One Channel Unity)

THD+N

< 0.03% (+4 dBu)

Analog Inputs

2× Combo XLR-1/4" Mic/Line Input
2× 1/4" Stereo Line Input (1 Stereo Pair)
1× 1/8" / 3.5 mm Stereo Line Input

Analog Outputs

2× XLR Balanced Stereo Output
2× 1/4" Unbalanced Stereo Output

Phantom Power

+48 V, Selectable On/Off (All Inputs)

AC Input Power

100 – 240 VAC, 50/60 Hz

DC Input Power

12 VDC

Power Supply Output

12 VDC at 2 A

Dimensions

2.9 × 7.5 × 8.4 in / 7.1 × 19 × 21.3 cm

Weight

2.6 lb / 1.2 kg

Package Weight

4 lb

Box Dimensions (L×W×H)

19 × 13 × 9 in
