Key Specifications

Number of Analog Input Channels

6

Number of Mic Preamps

2

Analog Output Channels

2× Stereo Master Output
1× Stereo Headphone Output

Mix Routing

Stereo Main Mix

Faders & Level Adjustment

No

Meters

Main Meter: 2× 8-Segment LED

Signal Processing

Gain / Trim Range

-20 dB to +40 dB

EQ

No

EQ Parameters

Low: ±15 dB at 80 Hz
High: ±15 dB at 12 kHz

Filters

High-Pass: 100 Hz, 18 dB/Octave

Built-In Effects

12 Factory Presets

Digital Audio

Sample Rates

Up to 192 kHz

Bit Depth

24-Bit

Performance

Frequency Response

Mic Input to Output: 20 Hz to 30 kHz (+0/-1 dB, Unity Gain)

Maximum Input Level

+22 dB

I/O Impedance

Mic Input: 3.8 Kilohms
Insert Return: 10 Kilohms
Line Input: ≥20 Kilohms
Headphone Output: 25 Ohms
Main Output: 120 Ohms (Unbalanced), 240 Ohms (Balanced)

Noise Floor

All Outputs: -95 dBu (Master Level at -∞, Channel Levels at -∞)
-80 dBu (Master Level at Unity, One Channel Level at Unity)

THD+N

Mic Input to Main Output: <0.03% (+4 dBu)

Connectivity

Analog Inputs

2× Combo XLR-1/4" Balanced/Unbalanced Mic/Line/Hi-Z Inputs
2× 1/4" TRS Balanced/Unbalanced Line Inputs (1 Stereo Pair)
1× 1/8" (3.5 mm) TRS Unbalanced Stereo Line Input

Analog Outputs

2× XLR 3-Pin Balanced Stereo Main Outputs (1 Stereo Pair)
2× 1/4" TRS Balanced/Unbalanced Main Outputs (1 Stereo Pair)
1× 1/4" TRS Unbalanced Stereo Headphone Output

Phantom Power

+48 V, Selectable On/Off (Applied to All Inputs)

Digital I/O

No

MIDI I/O

No

USB I/O

1× USB-B 2.0 (2-Track Recording, Audio Streaming, Host Connection)

USB I/O Capacity

2× Input / 4× Output

Wireless

Bluetooth

Compatibility

OS Compatibility

No

Power

AC Input Power

100 to 240 VAC, 50 / 60 Hz (Universal)

Power Supply Output

12 VDC at 2 A

Physical

Rack Mountable

No

Dimensions

7.5 × 8.4 × 2.9" / 190 × 213 × 74 mm

Weight

2.6 lb / 1.2 kg
