Key Specifications

System Type

Active Dual 15” bass reflex

Effects

5 Preset DSP management control

LF

15” woofer (2.5” voice coil)

HF

1” exit driver (1.77” voice coil)

Frequency Response

35Hz to 20KHz

SPL

103 dB SPL @ 1m

Coverage Angle

90° x 60°

Crossover Frequency

2.0KHz

Amp. Power

1200W Class-D Amplifier

Inputs

2 Balanced XLR & ¼” Combo connectors

Outputs

1 Balanced XLR Mix Output

AC Power Input

100V-240V 50/60Hz

Dimension (HxWxD)

536 x 446 x 1065 mm

Net Weight

37.15 Kg

Gross Weight

40.55 Kg

Packaging Size

590 x 500 x 1125 mm
