Key Specifications

Color/Finish

Black

Size/Weight

Dimensions (W x H x D)

1,200 mm x 136 mm x 404 mm (47-1/4” x 5-3/8” x 15-7/8”)

Weight

8.3 kg (18 lb, 5 oz) excluding batteries

Control Interface

Number of Keys / Type

76 / Organ-style

Touch Response

Yes (Soft, Medium, Hard, Fixed)

Controllers

Pitch Bend, Articulation Switches, 2 Control Knobs

Display

LCD with Backlight (English Language)

Voices & Effects

Tone Generation

AWM Stereo Sampling (64-Note Polyphony)

Number of Voices

820 (294 Panel + 28 Drum/SFX + 40 Arp + 458 XGlite)

Featured Voices

10 Premium Organ, 4 Live!, 9 Sweet!, 6 Cool!, 14 S.Art Lite

DSP Effects

DSP1: 41 types, DSP2: 12 types

Reverb / Chorus / EQ

12 Reverb, 5 Chorus, 4 Master EQ

Accompaniment & Performance

Preset Styles

290 (Multi finger, Smart Chord)

Groove Creator

35 Grooves (5 Sections per groove)

Quick Sampling

4 Samples; Approx. 9.6 sec (One-shot, Loop)

Special Functions

Mega Boost, 57 Motion Effect types, Melody Suppressor

Recording & Storage

User Songs

10 Songs (6 Tracks: 5 Melody + 1 Style/Groove)

USB Audio Recorder

80 min/song; WAV format (44.1 kHz, 16 bit, stereo)

Internal Memory

Approx. 1.72 MB (Supports USB Flash Drive)

Connectivity & Sound

Audio I/O

Mic Input, 2 x Standard Output, AUX IN, Headphones

USB Interface

USB TO DEVICE, USB TO HOST (Audio/MIDI interface)

Amplifiers / Speakers

12 W + 12 W / 12 cm x 2

Power Supply

Adaptor / Batteries

PA-300C / 6 x "D" size (LR20/R20/HR20)
