Key Specifications

Input Sensitivity

Microphone In to Full Power at the Power Amplifier, Master Volume Nominal:
Full: -40 dBu
Nominal: -22 dBu

Line In to Full Power at the Power Amplifier, Master Volume Nominal:
Full: -10 dBu
Nominal: +8 dBu

Equalizer

Channel:
Shelving EQ:
Low EQ: 80 Hz, ±15 dB

Mid-Morph:
Low: 250 Hz, ±15 dB
High: 4 kHz, ±15 dB

High EQ: 12 kHz, ±15 dB

Master:
63, 125, 250, and 500 Hz, ±12 dB
1, 2, 4, 8, and 12 kHz, ±12 dB

Frequency Response

Microphone to Main: 20 Hz to 20 kHz / +0, -1 dB
Line to Main: 20 Hz to 30 kHz / +0, -1 dB
Microphone to Amplifier: 50 Hz to 20 kHz / +0, -3 dB
Line to Amplifier: 40 Hz to 20 kHz / +0, -3 dB

Phantom Power

15 V

Noise

Main: Main line output, 22 to 22 kHz filter

Amp 1: Amplifier output, loaded at 4 ohms, through AP

AUX-0025 switching amplifier filter

All Controls Full Down:
Main: <-95 dBu
Amp 1: <-70 dBu

Master Volume Nominal:
Main: <-88 dBu
Amp 1: <-67 dBu

THD

All controls nominal:
<0.01% at Main Line Output, -30 dBu in Microphone Input Channel 1
<0.5% at Amp 1 @ 100 W into 4 ohms

All controls nominal:
<0.005% at Main Line Output, 4 dBu in Line Input Channel 1
<0.05% at Amp 1 @ 100 W into 4 ohms

Meter Array

Limit: -6, -12, -18, -24, and -30 dB

Limiter

Amplifier Limiter: Limits amplifier power just before clipping

Amplifier Output

Power:
120 VAC
Both channels loaded at 8 ohms:
60 W RMS per channel
120 W peak per channel

Both channels loaded at 4 ohms:
100 W RMS per channel
200 W peak per channel

Power Requirements

120 VAC, 50 / 60 Hz
74 W nominal

Dimensions

10.25 × 16.50 × 10.75" (26.04 × 41.91 × 27.31 cm)

Weight

20.4 lb (9.3 kg)

Packaging Info

Package Weight

24 lb

Box Dimensions (LxWxH)

19.3 × 13 × 12.5"
