Key Specifications
|
|
Input Sensitivity
|
Microphone In to Full Power at the Power Amplifier, Master Volume Nominal:
Full: -40 dBu
Nominal: -22 dBu
Line In to Full Power at the Power Amplifier, Master Volume Nominal:
Full: -10 dBu
Nominal: +8 dBu
|
|
Equalizer
|
Channel
Shelving EQ: 80 Hz, ±15 dB
Mid-Morph: Low: 250 Hz, ±15 dB, High: 4 kHz, ±15 dB
High EQ: 12 kHz, ±15 dB
Master
63, 125, 250, and 500 Hz, ±12 dB
1, 2, 4, 8, and 12 kHz, ±12 dB
|
|
MP3 Player
|
SD Card: Up to 32 GB SDHC Card
Portable Drive: Up to 32 GB Memory Device
|
|
File Format
|
MP3: 32 to 320 kb/s, CBR, VBR, All Sample Rates
WMA, ASF: 32 to 320 kb/s, All Sample Rates
WAV: All Sample Rates
|
|
Bluetooth
|
Bluetooth 3.0 + EDR System in 2.4 GHz ISM Band
Built-In Internal ROM for Program Memory
Built-in 32 KB RAM for Data Storage and Baseband Data Transfer Buffering
High-Speed HCI-UART (Universal Asynchronous Receiver Transmitter) Interface
Max +4 dBm Output Power with 20 dB Level Control from Register Control
Range: Up to 33.3' / 10 m
|
|
Clip LED Threshold
|
Comes On 3 dB Before Clipping
|
|
Frequency Response
|
All Controls Nominal (Detent)
Microphone to Main: 20 Hz to 20 kHz / +0, -1 dB
Line to Main: 20 Hz to 30 kHz / +0, -1 dB
Microphone to Amplifier: 50 Hz to 20 kHz / +0, -3 dB
Line to Amplifier: 40 Hz to 20 kHz / +0, -3 dB
|
|
Phantom Power
|
48 V
|
|
Noise
|
Main: Main Line Output, 22 Hz to 22 kHz Filter
Amp 1: Amplifier Output, Loaded at 4 Ohms, through AP
AUX-0025 Switching Amplifier Filter
All Controls Full Down:
Main: < -95 dBu
Amp 1: < -70 dBu
Master Volume Nominal:
Main: < -88 dBu
Amp 1: < -67 dBu
|
|
THD
|
All Controls Nominal
< 0.01% at Main Line Output, -30 dBu in Microphone Input Channel
< 0.5% at Amp 1 at 100 W into 4 Ohms
< 0.005% at Main Line Output, 4 dBu in Line Input Channel
< 0.05% at Amp 1 at 100 W into 4 Ohms
|
|
Meter Array
|
Limit: -6, -12, -18, -24, and -30 dB
|
|
Limiter
|
Amplifier Limiter: Limits Amplifier Power Just Before Clipping and Can Be Driven Up to 18 dB Past Maximum Output
|
|
Amplifier Output
|
Both Channels Loaded at 8 Ohms:
60 W RMS per Channel
120 W Peak per Channel
Both Channels Loaded at 4 Ohms:
100 W RMS per Channel
200 W Peak per Channel
|
|
Power Requirements
|
120 VAC, 50/60 Hz
74 W Nominal
|
|
Dimensions
|
11.2 × 19.4 × 10.7" / 28.6 × 49.2 × 27.3 cm
|
|
Weight
|
22.2 lb / 10.1 kg
|
|
Packaging Info
|
|
Package Weight
|
26.5 lb
|
|
Box Dimensions (LxWxH)
|
21.6 × 13 × 13"
|
