Key Specifications

Input

Video Inputs

2 × HDMI, 4 × BNC (3G-SDI), 2 × DVI-I DL (DVI/VGA)

Input Video Format

HDMI (4:4:4/4:2:2 RGB, YUV): UHD 4K at 30/50/60 fps, DCI 2K at 30/50/60 fps, 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps, 1080i at 50/59.94/60 fps, 720p at 23.98/24/25/29.97/30/50/59.94/60 fps, 576p at 50 fps, 576i / 625 lines at 50 fps

SDI (4:2:2 YUV): 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps, 1080i at 50/59.94/60 fps, 1080PsF at 23.98/24/25/29.97/30 fps, 720p at 23.98/24/25/29.97/30/50/59.94/60 fps, 480i / 525 lines, 576i / 625 lines

DVI / VGA: 1080p, WUXGA+ (1680 × 1050), UXGA (1600 × 1200), HD+ (1600 × 900), WXGA+ (1440 × 900), FWXGA (1366 × 768), 1360 × 768, SXVGA (1280 × 1024), SXGA- (1280 × 960), WXGA (1280 × 800), 1280 × 768, 720p, XGA+ (1152 × 864), XGA (1024 × 768), VGA (640 × 480)

Audio Inputs

1 × 2RCA Analog

Output

Video Outputs

2 × HDMI (Program), 2 × BNC (3G-SDI) (Program), 1 × USB-C

Output Video Format

HDMI / SDI: 1080p at 24/25/30/50/60 fps, 1080i at 50/60 fps

USB-C: WUXGA (1920 × 1200), 1080p, WUXGA+ (1680 × 1050), WXGA+ (1440 × 900), FWXGA (1366 × 768), SXGA (1280 × 1024), 1280 × 960, WXGA (1280 × 800), 720p, XGA (1024 × 768), 1024 × 576, 960 × 540, 856 × 480, SVGA (800 × 600), 576i / 625 lines, 720 × 576, 720 × 480, VGA (640 × 480), 640 × 360

Audio Outputs

1 × 2RCA Analog, 1 × 3.5 mm TS

Multiview Output

6-Way Multiview via HDMI

Connectivity

Other I/O

2 × USB-A Input, 1 × BNC Output, 1 × DB-25 Tally, 1 × RJ45 Firmware/LAN/Sync

Video Standard Compliance

SMPTE 259M / 292M / 424M

Display

Display Size

15.6"

Screen Resolution

1920 × 1080

Hardware

OS Compatibility

Windows 7 or Later, macOS 10.8 or Later, Linux 2.6 or Later

Wireless

No

Power

Power I/O

1 × Barrel Connector (12 VDC at 2.8 A) Input

Power Consumption

33 W

General

Operating Conditions

12 to 92°F / -20 to 60°C at 20 to 70% Humidity

Dimensions

14.8 × 10.7 × 1.7" / 375 × 272 × 44 mm

Weight

8.8 lb / 4 kg

Packaging Information

Package Weight

18.085 lb

Box Dimensions

21.5 × 16.6 × 7.1"
