LOGITECH RALLY
LOGITECH RALLY
|
Key Specifications |
|
|
Supported Resolutions (@ 30 fps) |
4K, 1440p, 1080p, 900p, 720p, SD |
|
Supported Resolutions (@ 30 & 60 fps) |
1080p, 720p |
|
Pan / Tilt / Zoom |
Pan: ±90° | Tilt: +50° / -90° | Zoom: 15x HD |
|
Field of View (Diagonal/Horizontal/Vertical) |
90° / 82.1° / 52.2° |
|
Features |
Autofocus, 3 presets, Kensington slot, Mute LED, Tripod thread, Privacy parking (Lens at -90° in sleep) |
|
RALLY MIC POD |
|
|
Pickup Range |
4.5m diameter |
|
Microphones |
Four omnidirectional forming eight acoustic beams |
|
Audio Processing |
AEC, VAD, Background noise suppression |
|
Connectivity / Daisy Chain |
Captive 2.95m 12-pin cable | Up to 7 Rally Mic Pods |
|
Frequency Response / Sensitivity / Data Rate |
90Hz – 16kHz / >-27dB +/-1dB @ 1Pa / 48 kHz |
|
Recommended Participants (Typical/Max) |
|
|
Rally (1 Mic Pod) / Rally Plus (2 Mic Pods) |
10 / 16 |
|
Max Participants (7 Mic Pods) |
46 (Add 6 participants per additional Mic Pod) |
|
RALLY SPEAKER |
|
|
Driver |
3" (76mm) high-performance driver with rare-earth magnet |
|
Max Volume (SPL @ ½ meter) |
95dB SPL @1W | 100dB SPL @7.5W (+/-2dB) |
|
Connectivity |
Mini XLR cable to Rally Display Hub (for signal and power) |
|
RALLY TABLE HUB |
|
|
Table Hub to Display Hub Link |
Single CAT6A cable (5m included, supports up to 50m customer-supplied) |
|
Connectivity |
USB Type C | USB Type A (Future) | USB Type B (to PC) | HDMI Type A passthrough (x2) | RJ45 (Future) | Power input |
|
Mic Pod Connectivity |
12 Pin connector for Rally Mic Pod (x1) |
|
Features |
Active speaker detection (analyzes 7 Mic Pods/56 beams every 8ms) |
|
RALLY DISPLAY HUB |
|
|
Connectivity |
HDMI Type A (x2 to displays) | USB C (to Camera) | USB Type B (to PC) | RJ45 (to Table Hub) | Mini XLR (x2 to Speakers) | Power input |
|
Power Output |
Powers one or two Rally Speakers |
|
REMOTE CONTROL |
|
|
Type / Power |
RF remote control (no line of sight required) / CR2032 batteries (included) |
|
CABLES (Included/Standard Length) |
|
|
Camera to Display Hub |
2m USB 3.1 Type C to USB Type C 3.1 |
|
PC to Display or Table Hub |
2m USB 3.1 Type A to USB Type B |
|
Display Hub to Table Hub |
5m CAT6A (supports up to 50 m customer-supplied) |
|
Display Hub to Speaker (x2) |
2.95m Mini XLR (supports 3m extension) |
|
PC to Displays (x2) |
2m HDMI A |
|
AVAILABLE ACCESSORIES |
|
|
Rally Mounting Kit |
Includes cable retainers (x2) and mounting brackets for camera, speakers (x2), and hubs (x2) |
|
Additional Audio Components |
Rally Mic Pod (up to 7 total), Rally Speaker (Add a second speaker) |
|
Rally Mic Pod Hub |
Connects 1-3 Mic Pods/hubs for flexible placement and under-table cabling |
|
Packaging Info |
|
|
Package Weight |
7.535 lbs |
|
Box Dimensions (L x W x H) |
11.6 x 10.5 x 7.2" |
