Key Specifications

Compatibility

Compatible Transmitters

Up to 2 × UH-280, UT-280, BG-24H, or BG-24T

Transmitter Charging Parameters

Charging Current

Fast charge 1.1 A; slow charge 500 mA

Charging Time

3 hours = 50% charged; 6 hours = 100% charged (battery capacity: 2600 mAh)

Sony Camera Battery Charging Parameters

Compatible Sony Camera Battery Charging Current

600 mA

Compatible Sony Camera Battery Charging Time

1.5 hours = 50% charged; 3 hours = 100% charged (battery capacity: 1500 mAh)

Power Supply & Daisy Chain

External Power Supply

DC 12V / 1A (maximum of 4 units can be connected in daisy chain)

External Power Supply Required (Daisy Chain)

12V / 2A (2 units)
12V / 3A (3 units)
12V / 4A (4 units)

Operating & Environmental Conditions

Operating Temperature Range

–18°C (0°F) to 50°C (122°F)

Storage Temperature Range

–29°C (–20°F) to 74°C (165°F)

Dimensions & Weight

Dimensions (mm)

185 (W) × 88 (D) × 86 (H)

Weight

Approx. 155 g
