Key Specifications

Product Type

Dual Audio Source (CD-MP3 / Tuner)

Audio Sources

CD, USB Pen Drive, SD Card, FM Tuner

Amplifier & Audio Specifications

Crosstalk (@ 1 kHz)

< 60 dB

Distortion (THD+N) @ 1 kHz

< 0.2 % (Nominal Power)

Signal/Noise Rate (A-weighted)

> 80 dB

Input & Output Section

Line Inputs

2 (Stereo RCA)

Signal Outputs

2 (Stereo RCA - Dedicated/Mixed)

GPI / GPO

11 General Purpose Inputs / 2 Outputs

Configuration & Control

Controls

Front panel / IR Remote Control

Priority Function

Yes (CD/MP3 over Tuner)

Power Requirement

Operating Voltage

220-240/115 V~ 50/60Hz

Cooling

Natural Convection

Physical Specifications

Cabinet Material / Color

Metal / Black

Rack Mounting

19", 1U

Dimensions (H x W x D)

44 x 482 x 185 mm / 1.73 x 18.98 x 7.28 inches

Weight

2.2 kg / 4.85 lbs

Shipping Information

Package Dimensions

110 x 550 x 300 mm / 4.33 x 21.65 x 11.81 inches

Package Weight

3.1 kg / 6.83 lbs
