Key Specifications

Product / Component Type

Audio Interface / RDNet Control Unit

Network / Control Interfaces

RDNet to MATRIX via RJ45 (Up to 100 m with CAT-5e Cable)

Input Audio Specifications

Input Connectors

3-Pin Female XLR, RCA

Input Impedance

5.1 kΩ

Maximum Input Level

+20 dBu

Input THD+N

<0.01% (Typical, 20 Hz – 20 kHz @ +4 dBu)

Input Frequency Response

20 Hz to 20 kHz (+0 dB, -0.5 dB)

Input Dynamic Range

-126 dB Max (A-Weighted)

Input Crosstalk

-87 dB Max (A-Weighted)

Output Audio Specifications

Output Connectors

2x 3-Pin Euroblock (5 mm Pitch)

Output Impedance

240 Ω

Maximum Output Level

+20 dBu

Output Frequency Response

20 Hz to 20 kHz

Output Dynamic Range

-107 dBu Max (A-Weighted)

Output Crosstalk

104 dB

Status Indicators & Physical Specifications

Signal Status Indicator

-30 dBu (Green LED, Peak-Reading)

Overload / Clip Indicator

+17 dBu (Red LED, Peak-Reading)

Item Dimensions (L×H×D)

147mm x 86mm x 47mm (5.79" x 3.39" x 1.85")
