Key Specifications

Sampling Frequency Rate

External: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, +4.1667%, +0.1%, −0.1%, −4.0% (±200 ppm)

Signal Delay

Less than 1.7 ms, Rio INPUT to Rio OUTPUT connect with PM10 using Dante, Fs = 96 kHz, Dante Receive Latency set to 0.25 msec

Total Harmonic Distortion

Less than 0.05% 20 Hz–20 kHz @ +4 dBu into 600Ω, Fs = 48 kHz, INPUT to OUTPUT, Input Gain = Min.

Less than 0.05% 20 Hz–40 kHz @ +4 dBu into 600Ω, Fs = 96 kHz, INPUT to OUTPUT, Input Gain = Min.

Frequency Response

+0.5, −1.5 dB 20 Hz–20 kHz, refer to +4 dBu output @ 1 kHz, INPUT to OUTPUT, Fs = 48 kHz

+0.5, −1.5 dB 20 Hz–40 kHz, refer to +4 dBu output @ 1 kHz, INPUT to OUTPUT, Fs = 96 kHz

Dynamic Range

112 dB typ., DA Converter; 108 dB typ., INPUT to OUTPUT, Input Gain = Min.

Hum & Noise Level

Equivalent Input Noise: −128 dBu typ., Input Gain = Max.

Residual Output Noise: −88 dBu, ST master off

Crosstalk

−100 dB, adjacent INPUT/OUTPUT channels, Input Gain = −6 dB @ 1 kHz
*Measured with a 30 dB/octave filter @ 22 kHz

Power Requirements

100–240V, 50/60 Hz

Power Consumption

120 W

Dimensions

W: 480 mm (18.9")

H: 220 mm (8.7")

D: 368 mm (14.5")

Net Weight

13.5 kg (29.8 lbs)

Accessories

Owner’s Manual, AC power cord (250 cm)

Others

NC Value: FAN MODE LOW: NC=20 / HIGH: NC=30 (Measurement position: 1 m from the front of the unit)

Operating temperature range: 0–40°C

Storage temperature range: −20–60°C
