Key Specifications

Connection Type

Loudspeaker Connectors

Chassis Shape

D-Shape

Mounting Direction

Front mounting or rear mounting

Wiring Termination

Flat tab (4.8 × 0.5 mm) or soldering

Electrical Specifications

Rated Current

Continuous 30 A rms

Rated Voltage

250 V

Contact Resistance

≤5 mΩ

Insulation Resistance

>1 GΩ

Dielectric Strength

4 kV dc

Mechanical & Material Specifications

Mechanical Lifetime

>1000 Mating Cycles

Contact Material & Plating

Bronze (Silver / Ag Plated)

Shell Material

PA6+30%GF

Environmental Specifications

Operating Temperature Range

-30°C to +80°C

Flammability Rating

UL94 V-0

Solderability Standard

Complies with IEC 68-2-20
