Key Specifications

Model

RM-CR

Dimensions (W × D × H)

215 × 260 × 44 mm

Weight

1.6 kg

Supported Operating Systems

Windows 11
Windows 10 (32-bit / 64-bit)
Windows 8.1 (32-bit / 64-bit)
macOS 12
macOS 11
macOS 10.15

Power Requirements

PoE+ (IEEE 802.3at, LLDP), DC 48 V

Maximum Power Consumption

15 W

Connectors

RJ45, USB, XLR (Balanced), RCA

Operating Temperature

0 °C to 40 °C

Operating Humidity

30% – 90% (Non-condensing)

Storage Temperature

-20 °C to 60 °C

Storage Humidity

20% – 90% (Non-condensing)

Indicators

Power Indicator
Status Indicator
Bluetooth Indicator
Network Port Indicator (×3)

Mounting Options

Table Mount, Rack Mount

Included Accessories

Installation Manual
USB Cable (A–B), 5 m (16.4 ft)
USB Cable (A–Micro B), 1 m (3.3 ft)
4 × Rubber Feet
Access Panel

Optional Accessories

RM-MTL: Table Mount Kit
RM-MRK: Rack Mount Kit

Network Specifications

Ethernet 1

Dante Audio / Dante Control, Remote Control, Web UI, PoE+

Ethernet 2 / Ethernet 3

Corporate Network, Remote Control, SIP, Web UI

USB Network

USB 2.0, Network Class, Web UI, Fixed IP

Audio Specifications

Dante Audio I/O

16 Inputs / 16 Outputs

USB Audio

USB 2.0, Audio Class 1.0, 2-channel Input / 2-channel Output @ 48 kHz

Mic Input

XLR Balanced, 2-channel Input

AUX I/O

RCA Unbalanced (Line Level), 2-channel Input / 2-channel Output

Speaker Output

RCA Unbalanced (Line Level), 2-channel Output

Bluetooth Specifications

Bluetooth Version

Bluetooth 4.2

Supported Profiles

HFP (1.6), A2DP, AVRCP

Supported Codecs

CVSD, SBC, mSBC

Wireless Output

Class 2

Maximum Communication Distance

10 m / 32.8 ft (No obstacles)

Radio Frequency

2.402 – 2.480 GHz

Maximum Output Power (EIRP)

4.0 dBm (2.5 mW)

SIP & Audio Processing

Call Handling

Dial, Answer, Hold, Resume, Forwarding
Do Not Disturb, Caller ID, Voicemail Notifications

Call Bridging

Supports SIP, USB, Bluetooth, and AUX Calls
Join, Split, Hold, Resume
5+1 Lines: 2 SIP, 1 USB, 1 Bluetooth, 1 AUX, plus User

SIP Codecs

G.711, G.722HD, G.729ab, G.726

DTMF Support

RTP Event, SIP In-band, SIP INFO Package

Security

SRTP (RFC 1889), SIP (RFC 3261 and related RFCs)

Sampling Rate

48 kHz

Bit Depth

24-bit

Latency

8 ms (Dante In to USB Out, including processing)

Frequency Response

20 Hz – 20 kHz
