Key Specifications

Model

Yamaha RMTT

Color

White

Frequency Response

160 Hz – 16 kHz (-10 dB)

Sampling Rate

48 kHz

Bit Depth

24-bit

Latency

57 ms (Including signal processing)

Audio & Performance

Dante Audio

1 × Input
2 × Outputs

Maximum Input Level

106.8 dB SPL

Self Noise

6.3 dBA SPL

Signal-to-Noise Ratio

87.7 dBA (Ref. 94 dB SPL @ 1 kHz)

Sensitivity

-12.8 dBFS/Pa

Dynamic Range

100.5 dBA

Signal Processing

Auto Voice Tracking
AEC, Noise Reduction, Dereverberation
Auto Mixer, AGC
User PEQ, Output Gain

Selectable Polar Patterns

Cardioid
Hypercardioid
Supercardioid
Omnidirectional
Bidirectional
Toroidal

Network & Control

Ethernet

Dante Audio / Dante Control, Remote Control, Web UI, PoE

Cable Requirements

Cat 5e or higher (STP)

Indicators

Status Indicators

Mute Indicator (Mute / Unmute)
Status Indicator (Ring)
Network Port Indicator

Power & Environmental

Power Requirements

PoE (IEEE 802.3af)

Maximum Power Consumption

4.5 W

Operating Temperature

32 to 104 °F / 0 to 40 °C

Storage Temperature

-4 to 140 °F / -20 to 60 °C

Operating Humidity

30% – 90% (Non-condensing)

Storage Humidity

20% – 90% (Non-condensing)

Physical

Dimensions (W × D × H)

5.5 × 5.5 × 1.6 in / 140 × 140 × 41.5 mm

Weight

10.9 oz / 310 g
