RUIO16-D

Dante/USB audio interface for live sound applications
Allows you to process live sound through VST plug-ins via VST Rack Pro software (Mac/Win)
Comes with 30+ plug-ins, including Buss Comp 369, SuperVision, REV and RoomWorks reverbs, VCM EQs and compressors, and more
Supports VST and VST3 plug-in formats
Connects to your Dante-compatible digital mixer via 16x16-channel Dante interface
Connects to your host computer via USB (cables included) for plug-in processing
Additional analog connectivity includes 2 mic inputs with phantom power, and 2 line-level XLR outputs
Front-panel Bypass button disengages USB throughput

YAMAHA

₱94,900.00 VAT INC.

₱94,900.00

UNIT: PIECE/S

Product Code: SKU:YAMH-RUIO16D-CHN-754

Dante/USB audio interface for live sound applications
Allows you to process live sound through VST plug-ins via VST Rack Pro software (Mac/Win)
Comes with 30+ plug-ins, including Buss Comp 369, SuperVision, REV and RoomWorks reverbs, VCM EQs and compressors, and more
Supports VST and VST3 plug-in formats
Connects to your Dante-compatible digital mixer via 16x16-channel Dante interface
Connects to your host computer via USB (cables included) for plug-in processing
Additional analog connectivity includes 2 mic inputs with phantom power, and 2 line-level XLR outputs
Front-panel Bypass button disengages USB throughput

Authorized Dealer

Certified Quality Products

After-Sales Support

Secure Payments

Quantity

YAMAHA RUIO16-D

Key Specifications
Type	Dante Audio Interface
Compatibility	Mac / PC
Software	VST Rack Pro
OS Requirements	macOS 10.15 or later / Windows 10 or later
Audio / I/O
Simultaneous I/O	16 × 16 (Dante), 18 × 16 (USB 2.0)
Number of Preamps	2
Phantom Power	Yes
Analog Inputs	2 × XLR
Analog Outputs	2 × XLR
Headphones	1 × 1/4"
USB I/O	2 × USB-C (host, power)
Data / Network	2 × etherCON (Primary, Secondary), Dante
Power
Bus Powered	Yes
Power Supply	USB Bus Powered / 5V DC Power Supply
Physical
Height	1.65"
Width	7.1"
Depth	4.76"
Weight	2.2 lbs
Manufacturer Part Number	RUio16-D
