S12
S12
RCF
UNIT: PIECE/S
Product Code: SKU:RCF-S12-CHN-923
Key Features
RCF S12
RCF S12
|
Key Specifications |
|
|
Frequency Response (-10 dB) |
40 Hz - 200 Hz |
|
Max SPL @ 1m |
125 dB |
|
System Sensitivity |
93 dB |
|
Power Section |
|
|
Power Handling |
400 W RMS / 1600 W PEAK |
|
Nominal Impedance |
8 Ω |
|
Recommended Amplifiers |
DMA 162, DMA 162P, DMA 504, IPS 1.5K, IPS 2.5K, QPS 6.0K |
|
Transducers |
|
|
Woofer |
1 x 12'', 2.5'' v.c. |
|
Input / Output Section |
|
|
Input Connectors |
Euroblock |
|
Output Connectors |
Euroblock |
|
Standard Compliance |
|
|
Safety Agency |
CE compliant |
|
Physical Specifications |
|
|
Cabinet / Case Material |
Plywood |
|
Hardware |
12 x M10 |
|
Pole Mount / Cap |
M20 thread |
|
Grille |
Steel with clothing |
|
Color |
Black |
|
Dimensions (H x W x D) |
373 x 530 x 425 mm / 14.69 x 20.87 x 16.73 inches |
|
Weight |
24.6 kg / 54.23 lbs |
|
Shipping Information |
|
|
Package Height |
423 mm / 16.65 inches |
|
Package Width |
470 mm / 18.5 inches |
|
Package Depth |
575 mm / 22.64 inches |
|
Package Weight |
27.4 kg / 60.41 lbs |
RCF S12 Accessories
- No accessories available.
