Key Specifications

Connectivity Architecture

AES50 SuperMAC Networking

Analog Inputs

32x XLR (Midas-Designed Preamps)

Analog Outputs

16x XLR (Servo-Balanced)

Digital Outputs

2x ADAT (Optical) / 2x AES/EBU (XLR)

Audio Performance

Sample Rates

44.1 / 48 kHz (24-bit Conversion)

Frequency Response

10 Hz to 22 kHz (0 / -1 dB)

System Latency

1.1 ms (Stagebox In > Console > Stagebox Out)

Networking & Monitoring

AES50 Ports

Dual Ports (Cascadeable / Redundant)

Ultranet Port

16-Channel Power over Ethernet (for P16-M)

Max Cable Length

100 m (328 ft) via Shielded Cat 5e

Physical & Power

Rack Space

3U Rackmount

Power Consumption

55 W (Auto-ranging 100-240V)

Weight

5.6 kg (12.4 lbs)
