Key Specifications

Power Source

12 V DC, 2 A (Optional AC Adapter: AD-5000-2)

Power Consumption

15 W (Rated) / 25 W (Maximum)

Sound Pressure Level

113 dB (1 W, 1 m) | Max SPL > 120 dB

Frequency Response

250 Hz – 10,000 Hz

Audio & Gain Control

Input

0 dB, 10 kΩ, Unbalanced (RCA Plug)

Signal Gain

8, 16, 24, 32 dB (Selectable)

Volume Control

Internal adjustment (Pre-set to Max)

Environmental & Physical

Dust/Water Protection

IP65 (Weatherproof)

Operating Temp

-20 °C to +55 °C

Dimensions

292 (W) × 230 (H) × 280 (D) mm

Weight

1.8 kg (3.97 lbs)
