Key Specifications

Channels of I/O

2 Inputs / 2 Outputs (Analog) @ 192 kHz

Maximum Sampling Rate

192 kHz / 24-Bit

Microphone Inputs

2

Analog Audio I/O

2× XLR 3-Pin Balanced Mic Inputs
2× 1/4" TRS Balanced/Unbalanced Line/Hi-Z Inputs (Front)
2× 1/4" TRS Balanced Monitor Outputs
1× 1/4" TRS Headphone Output (Front)

Digital Audio I/O

None

Phantom Power

48 V, Selectable On/Off

Gain / Trim Range

Mic/Line: Up to +69 dB
Hi-Z: 62 dB

Frequency Response

Mic Inputs: 20 Hz – 20 kHz (±0.06 dB)
Line Inputs: 20 Hz – 20 kHz (±0.05 dB)
Hi-Z Inputs: 20 Hz – 20 kHz (±0.15 dB)

Maximum Input Level

Mic: +16 dBu
Line: +22 dBu
Hi-Z: +12 dBu

Maximum Output Level

Line Outputs: +16 dBu

Dynamic Range

Mic Inputs: 116 dBA
Line Inputs: 115.2 dBA
Hi-Z Inputs: 113 dBA
Line Outputs: 120 dB
Headphones: 112–115 dB
A/D: 120 dB
D/A: 130 dBA

THD+N

Mic Inputs: -100 dB
Line Inputs: -100 dB
Hi-Z: -80 dB
Line Outputs: -109 dB
Headphones: -99 to -108 dB
A/D: -110 dB
D/A: -115 dB

EIN

-127 dBu (A-Weighted)

Host Connection

1× USB-C (USB 2.0)

OS Compatibility

macOS / Windows / iPadOS

Power Requirements

USB Bus Power or 5 VDC (900 mA Adapter Not Included)

Power Consumption

4.5 W

Dimensions (W × D × H)

7.1 × 4.6 × 1.87" (18 × 11.7 × 4.75 cm)

Weight

1.3 lb (595 g)

Package Weight

5.64 lb

Box Dimensions (L × W × H)

15.5 × 10.3 × 4.9"
