Key Specifications

Video I/O

Input
1x BNC (3G-SDI)
Output
1x BNC (3G-SDI) (Loop Output)

Audio I/O

Input
1x 1/8" / 3.5 mm TRS

Video Resolution

SDI Input/Output
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1920 x 1080i at 50/59.94/60 fps
1280 x 720 at 23.98/24/25/29.97/30/50/59.94/60 fps
720 x 576p at 50 fps
720 x 576i at 50 fps
640 x 480p at 60 fps
640 x 480i at 59.94/60 fps

IP Video

Encoding via H.264/H.265
640 x 360 to 1920 x 1080

IP Audio

Encoding
AAC/G.711/MP3/MPEG Layer 2

Wireless

No

Inputs/Outputs

Video I/O

Input
1x BNC (3G-SDI)
Output
1x BNC (3G-SDI) (Loop Output)

Audio I/O

Input
1x 1/8" / 3.5 mm TRS

Other I/O

Input
1x RJ45 (10/100/1000 Ethernet)

Expansion Slots

No

Format Support

Video Resolution

SDI Input/Output
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1920 x 1080i at 50/59.94/60 fps
1280 x 720 at 23.98/24/25/29.97/30/50/59.94/60 fps
720 x 576p at 50 fps
720 x 576i at 50 fps
640 x 480p at 60 fps
640 x 480i at 59.94/60 fps

Embedded Audio

SDI

Reclocking

No

Standards

HDR Support

No

IP Streaming

IP Video

Encoding via H.264/H.265
640 x 360 to 1920 x 1080

IP Audio

Encoding
AAC/G.711/MP3/MPEG Layer 2

Transport Protocols

HTTP, RTMP, RTP, RTSP, SRT, UDP

Hardware

Wireless

No

Power

Power I/O

1x Barrel (12 VDC) Input

Power Consumption

5 W

General

Operating Conditions

14 to 140°F / -10 to 60°C

Storage Conditions

-4 to 158°F / -20 to 70°C

Dimensions

4.1 x 3 x 1" / 104 x 76 x 25 mm

Weight

12 oz / 340 g

Packaging Info

Package Weight

1.325 lb

Box Dimensions (LxWxH)

6.9 x 6 x 2.9"
