Key Specifications

Mix Effects

Available M/E Layers

2 M/E

Effect Types

1 × Luma Key

Downstream Keys

1 × Chroma
1 × Luma

Generators

1 × Pattern
2 × Color

Audio Mixing

2-Channel Mixing

Processing

Switching Type

Pushbutton, Software, T-Bar

Processing Resolution

1080p at 23.98/24/25/29.97/30/50/59.94/60

Color Processing

RGB
YCbCr

Input

Number of Video Input Sources

4

Video Inputs

2 × HDMI Female
2 × BNC (3G-SDI) Female

Input Video Format

BNC / HDMI:
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080i at 50/59.94/60 fps

Audio Inputs

2 × 1/8" / 3.5 mm TRS Stereo Analog Female

Input Audio Format

Analog

Embedded Audio Input

HDMI: 2-Channel
SDI: 2-Channel

Output

Video Output Channels

5

Video Outputs

2 × HDMI Female (Program)
1 × HDMI Female (Monitor)
1 × USB-C (USB Video) Female (Program)
1 × USB-A (USB Video) Female (Program)

Output Video Format

HDMI:
1080p at 24/25/30/50/60 fps
1080i at 50/60 fps
USB-C:
1080p at 60 fps

Audio Outputs

1 × 1/8" / 3.5 mm TRS Stereo Analog Female (Loop Output)

Embedded Audio Output

HDMI
USB-C

Multiview Output

4-Way Multiview via HDMI

Monitor Output

1 × HDMI

Connectivity

Other I/O

1 × RJ45 LAN Input
1 × DE-15/DB-15 Tally Input/Output
1 × USB-A Input

HDCP Support

No

IP Encoding/Decoding

IP Video

1920 × 1080 Encoding

Transport Protocols

RTMP, RTMPS, SRT

Simultaneous Streams

1 Stream

Compatible Services

Facebook Live, Instagram, Livestream, Skype, Twitch, YouTube Live

Internal Recording

Recording Media

1 × SD (Unspecified Type)

Display

Display Size

10.1"

Screen Resolution

1920 × 1080

Hardware

Processor

Not Specified by Manufacturer

Wireless

No

Power

Power I/O

1 × Barrel (12 VDC at 2 A) Input

Power Consumption

Device: 24 W

General

Operating Conditions

-4 to 122°F / -20 to 50°C

Dimensions

10.29 × 7.63 × 2.3" / 26.14 × 19.39 × 5.8 cm

Weight

3.81 lb / 1.73 kg

Packaging Information

Package Weight

5.065 lb

Box Dimensions (L × W × H)

12.6 × 10.5 × 4.2"
