Key Specifications

Total Channels

14 Channels

Mic Preamps

12 x High-Headroom Studio Grade

Phantom Power

Yes (Studio Grade +48V)

Inputs

12 x XLR (Balanced), 14 x 6.3 mm Jack

Outputs

2 x XLR, 2 x 6.3 mm (Balanced), Control Room Out

Digital Effects (DSP)

16 Presets (Reverbs, Mod, Delays, Rotary)

USB Interface

16-bit / 48 kHz (Plug and Play)

Auxiliary Sends

2 x Aux Sends per Channel

Technical Performance

Equivalent Input Noise (EIN)

-127 dBu ±5 dBu (Mic Pre)

Frequency Response

20 Hz – 20 kHz (±2 dB)

Channel Strip Features

3-Band EQ, HPF, PFL, Pan/Balance

Physical Specifications

Dimensions (H x W x D)

80 x 400 x 475 mm

Net Weight

6.85 kg
