Key Specifications

Number of Analog Input Channels

14

Number of Mic Preamps

8

Analog Output Channels

1 x Stereo Master Output
1 x Stereo Control Room / Monitor Output
2 x Mono Bus / Subgroup Output
1 x Mono FX Send Output
1 x Stereo Headphone Output

Faders & Level Adjustment

1 x 2.4" / 60 mm Channel Fader

Signal Processing

Gain / Trim Range

Hi-Z Input: 50 dB to 0 dB
Line Input: -20 dB to +30 dB
Stereo Line Input: -15 dB to +25 dB
Line/Mic Input: 0 dB to +50 dB
Stereo Input: +5 dB to +45 dB

EQ

3-Band Semi-Parametric

EQ Parameters

Mono Channels
High: ±15 dB @ 12 kHz (Shelving)
Mid: ±15 dB @ 140 Hz–3.5 kHz, Q 0.55 (Semi-Parametric)
Low: ±15 dB @ 80 Hz (Shelving)

Stereo Channels
High: ±15 dB @ 12 kHz (Shelving)
Mid: ±15 dB @ 2.5 kHz, Q 0.55 (Peak/Notch)
Low: ±15 dB @ 80 Hz (Shelving)

Filters

High-Pass Filter: 100 Hz, 18 dB/Octave

Solo / Mute

Mute, PFL per Input Channel

Built-In Effects

Yes

Digital Audio

Sample Rates

44.1 / 48 / 88.2 / 96 kHz (AD/DA)
44.1 kHz (Stereo Record)

Bit Depth

24-Bit

Performance

Frequency Response

20 Hz to 20 kHz (+0.5 / -1.5 dB)
USB: Up to 40 kHz

Max Input Level

Mic Input: +22 dBu @ Unity Gain
Line Input: +22 dBu @ Min Gain
Hi-Z Input: +22 dBu @ Min Gain

Analog Dynamic Range

Headphone Output: > 103 dBA
Output: > 105 dB (Min Gain), > 100 dB (Mid Gain)
Hi-Z Input: > 108 dBA

Headphone Output Power

150 mW per Channel into 60 Ohms

SNR

Line Input to Output: 94 dB (+4 dBu Reference)
Mic Input to Output: 94 dB (+4 dBu Reference)

THD+N

< 0.01%

Connectivity

Analog Inputs

XLR 3-Pin Mic Input
1/4" TRS Balanced Line Input
1/4" TS Unbalanced Hi-Z Input

Analog Outputs

XLR 3-Pin Balanced Main Output
1/4" TRS Control Room Output
1/4" TRS Monitor Output
1/4" TRS FX Output
1/4" TRS Headphone Output

Phantom Power

+48 V ±3 V (Global On/Off)

USB I/O

1 x USB-C 2.0

Wireless

Bluetooth 5.0

Recording

Media Support

SD / SDHC (Up to 32 GB)

File Format

WAV (Record), MP3 / WAV (Playback)

Power

AC Power

90–240 VAC, 50 / 60 Hz

Physical

Rack Mountable

Yes

Dimensions

3.7 x 16 x 15.4" / 9.4 x 40.6 x 39.1 cm

Package Weight

14.445 lb

Box Dimensions

19.1 x 18.3 x 7.5"
