Key Specifications

Speaker

• Active/Passive: Passive
• Number of Included Speakers: 1
• Speaker Configuration: Full-Range
• Power Handling: 80 W Program; For 2 Hours: 40 W, 160 W Peak; For 100 Hours: 20 W, 80 W Peak
• Constant Voltage / Transformer Taps: 70 V: 15 / 7.5 / 3.8 / 1.9 W or 8 Ohms Bypass; 100 V: 15 / 7.5 / 3.8 W or 8 Ohms Bypass
• Impedance: 7.5 to 8 Ohms
• Transformer Wattage: 15 W
• Enclosure Type: Sealed

Drivers

• Full-Range Driver: 1x 3" / 7.6 cm Polypropylene-Coated Cone (Voice Coil: 0.8" / 2 cm)

Performance

• Frequency Range: 74 Hz to 20 kHz -10 dB
• Frequency Response: 91 Hz to 18 kHz ±3 dB
• Sensitivity: 84 dB (Half-Space)
• Coverage Angle: 120° H x 120° V
• Directivity: 7.5 (Directivity/Q Factor), 8.8 dB (Directivity Index)
• Recommended High-Pass Filter: 70 Hz, 24 dB/Octave
• Maximum Input Voltage: 15 V RMS, 30 V Peak
• Transformer Insertion Loss: <1 dB

Connectivity

• Inputs/Outputs: 1x Block 4-Pin Speaker Input (Locking, Removable)
• Maximum Wire Gauge: 24 AWG

Physical

• Environmental Resistance: Dust/Water-Resistant (IP44)
• Color: White
• Mounting: 1x Bracket Point (Rear)
• Rotation Range: No
• Construction Material: ABS, Polycarbonate
• Dimensions: 9.8 x 9.1 x 3.9" / 24.9 x 23.1 x 9.9 cm
• Weight: 4.2 lb / 1.9 kg

Packaging Info

• Package Weight: 10.545 lb
• Box Dimensions (L x W x H): 13.9 x 13.5 x 9.2"
