Key Specifications

Speaker

• Active/Passive: Passive
• Number of Included Speakers: 1
• Speaker Configuration: 2-Way
• Power Handling: For 2 Hours: 40 W, 100 W Program, 200 W Peak; For 100 Hours: 30 W, 120 W Peak
• Constant Voltage / Transformer Taps: 70 V: 25 / 12.5 / 6.3 / 3.2 W or 8 Ohms Bypass; 100 V: 25 / 12.5 / 6.3 W or 8 Ohms Bypass
• Impedance: 7.1 to 8 Ohms
• Transformer Wattage: 25 W
• Enclosure Type: Sealed

Drivers

• HF Driver: 1x 0.79" / 2.01 cm Titanium Dome Tweeter
• LF Driver: 1x 4.5" / 11.4 cm Polypropylene Woofer (LF Voice Coil: 1" / 2.5 cm)
• Magnet: Neodymium

Performance

• Frequency Range: 70 Hz to 20 kHz -10 dB
• Frequency Response: 80 Hz to 18 kHz ±3 dB
• Sensitivity: 85 dB (Half-Space)
• Coverage Angle: 140° H x 120° V
• Directivity: 6.9 (Directivity/Q Factor), 8.4 dB (Directivity Index)
• Recommended High-Pass Filter: 70 Hz, 24 dB/Octave
• Maximum Input Voltage: 18 V RMS, 36 V Peak
• Transformer Insertion Loss: <1 dB

Connectivity

• Inputs/Outputs: 1x Block 4-Pin Speaker Input (Locking, Removable)
• Maximum Wire Gauge: 24 AWG

Physical

• Environmental Resistance: Dust/Water-Resistant (IP44)
• Color: White
• Mounting: 1x Bracket Point (Rear)
• Rotation Range: No
• Construction Material: ABS, Polycarbonate
• Dimensions: 11.3 x 10.4 x 3.9" / 28.7 x 26.4 x 9.9 cm
• Weight: 6.2 lb / 2.8 kg

Packaging Info

• Package Weight: 13.765 lb
• Box Dimensions (L x W x H): 14.9 x 13.1 x 9.5"
