Key Specifications

Microphone Type

Small Diaphragm

Polar Pattern

Cardioid

Element Type

Electret Condenser

Controls

Pad, Low Cut/HPF

Frequency Response

20 Hz to 20 kHz

Maximum SPL

136 dB (146 dB with Pad)

Analog Output

1x XLR 3-Pin

Power Sources

Phantom Power

Microphone

Sound Field

Mono

Orientation

End Address

Pad

-10 dB (Lockable)

Filter & EQ

80 Hz (18 dB/Octave) / 100 Hz (6 dB/Octave)

Performance

Sensitivity

-45 dBV/Pa (5.6 mV) at 1 kHz

Output Impedance

150 Ohms (85 Ohms Actual)

Equivalent Noise Level

16 dB (A-Weighted)

Signal-to-Noise Ratio

78 dB at 94 dB SPL

Power

Operating Voltage

11 to 52 VDC (Phantom Power)

Current Drain

1.2 mA (Max)

Physical

Color

Silver (Vinyl Metallic Paint)

Dimensions

ø: 0.79 x L: 8.4" / ø: 20 x L: 212 mm

Weight

0.5 lb / 0.23 kg

Packaging Info

Package Weight

1.625 lb / 0.74 kg

Box Dimensions (LxWxH)

11.9 x 6.05 x 3.05"
