Key Specification

Speaker Configuration

1 × 2-Way Speaker Column with Subwoofer

Number of Input Channels

6 (2 × Mono, 2 × Stereo)

Amplifier Power Rating

Total: 1300 W Peak
LF: 1000 W Peak
HF: 300 W Peak

HF Driver

6 × 2" / 5.08 cm Dome Tweeter

LF Driver

1 × 10" / 25.4 cm Woofer

Audio I/O

2 × Combo XLR-1/4" TRS Mic/Line/Hi-Z Input
2 × 1/4" TRS Line Input
1 × 1/8" / 3.5 mm TRS Aux Input
1 × XLR 3-Pin Male Line Output

USB I/O

No

Bluetooth

4.2

Amplifier Class

HF/LF: Class-D

Enclosure Type

Speaker: Sealed
Subwoofer: Sealed

Magnet

LF Driver: Ferrite

Crossover

600 Hz, 18 dB/Octave Butterworth (Internal)

EQ

LF Shelf: -15 to +5 dB at 90 Hz
HF Shelf: -15 to +5 dB at 6 kHz

Semi-Parametric EQ

No

Effects

3 × Reverb

Filters

No

Dynamic Processing

No

Frequency Range

40 Hz to 20 kHz (-10 dB)
50 Hz to 20 kHz (±3 dB)

Maximum SPL

118 dB (Peak)

Coverage Angle

90° H × 40° V

Gain Range

Mic/Line: Up to +16 dB
Bluetooth: Up to +10 dB

I/O Impedance

XLR Mic Input: 8 Kilohms
XLR Line Input: 8 Kilohms
1/4" TRS Line Input: 8 Kilohms
1/4" TS Hi-Z Input: 1 Megohm
XLR Line Output: 600 Ohms

Protections

Infrasonic, Output Limiter, Power Supply, RMS, Thermal

Network I/O

No

Wireless Connectivity

Bluetooth

Bluetooth Pairing

Manual

Bluetooth Power Class

1

AC Input Power

100 to 240 VAC, 50 / 60 Hz

Power Consumption

110 W

AC Power I/O

1 × IEC Input

Transport Options

1 × Carry Case
Subwoofer: 1 × Handle (Top)

Cooling

Convection

Construction Material

Perforated Metal Grille, Polypropylene, Steel

Environmental Resistance

No

Operating Conditions

32 to 104°F / 0 to 40°C

Dimensions

79 × 14.2 × 13" / 200.66 × 36.07 × 33.02 cm

Weight

29.6 lb / 13.43 kg

Package Weight

42 lb

Box Dimensions (L × W × H)

27 × 23 × 20"
