Key Specifications

Speaker Type

Active Loudspeaker/Stage Monitor

Configuration

2-Way

Total Output Power

2000 W Peak

LF Driver

1 × 15" / 38 cm Woofer

Frequency Range/Response

40 Hz to 20 kHz

Enclosure Type

Bass-Reflex

Amplifier Power Rating

Low Frequency (LF): 1800 W Peak
Mid Frequency (MF): 200 W Peak

Amplifier Class

Class-D

Drivers

LF Driver

1 × 15" / 38 cm Woofer

Performance

Frequency Range/Response

40 Hz to 20 kHz

Maximum SPL

136 dB SPL (Peak)

Coverage Angle

90° H × 60° V

Protections

Crossover Overload, Infrasonic, Output Limiter,
Thermal, Transducer Overdrive, Ultrasonic

Signal Processing

EQ & Filters

No

Alignment Delay

Up to 100 ms (112.5' / 34.2 m)

Digital Signal Processing

Delay, Reverb, User Settings, Venue Settings, Voicing Modes

Connectivity

Audio I/O

1 × Combo XLR-1/4" TRS Mic/Line Input
1 × Combo XLR-1/4" TRS Mic/Line/Hi-Z Input
1 × 1/8" / 3.5 mm TRS Aux Input
2 × XLR 3-Pin Line Output
1 × XLR 3-Pin Mix Output

Network I/O

No

USB I/O

No

Wireless

Bluetooth

Mobile App Compatible

No

Power

AC Input Power

110 to 240 VAC, 50 / 60 Hz

AC Power I/O

1 × IEC Input

Physical

Color

Black

Mounting

1 × 1.38" / 35 mm Dual-Angle Pole Socket (Bottom)

Handles

1 × Each Side, 1 × Top

Construction Material

Polypropylene

Environmental Resistance

No

Dimensions

28.8 × 15.4 × 17.6" / 731.5 × 391.2 × 447 mm

Weight

48.9 lb / 22.2 kg

Packaging Info

Package Weight

55.8 lb

Box Dimensions (L × W × H)

32.2 × 20.85 × 18.5"
