Key Specifications

General

• Speaker Type: Active Line Array Loudspeaker
• Configuration: 2-Way
• Total Output Power: 600 W RMS / 880 W Peak
• Amplifier Class: Class-D

Amplifier Power Rating

• Low Frequency (LF): 400 W RMS / 580 W Peak
• Mid Frequency (MF): 200 W RMS / 300 W Peak

Drivers

• LF Driver: 2x 10" / 25.4 cm Woofer (Voice Coil: Dual 2" / 50.8 mm, Magnet: Neodymium)
• HF Driver: 1x 1.5" / 38.1 mm Horn-Loaded Compression Driver (Voice Coil: 3" / 76.2 mm)

Performance

• Frequency Range/Response: 53 Hz to 19 kHz (-10 dB), 60 Hz to 18 kHz (-3 dB)
• Maximum SPL: 135 dB (Peak)
• Coverage Angle: 105° H

Signal Processing

• EQ & Filters: No
• Alignment Delay: Up to 2000 ms (2200' / 670.56 m)
• Digital Signal Processing: Delay, FIR Filter (Adjustable via Optional Software)

Connectivity

• Audio I/O: 2x XLR 3-Pin Line Output/Input
• Network I/O: 2x etherCON/RJ45 (Ethernet)
• USB I/O: No
• Wireless: No
• Mobile App Compatible: No

Power

• AC Input Power: 100 to 240 VAC, 50 / 60 Hz
• AC Power I/O: 1x powerCON TRUE1 Input, 1x powerCON TRUE1 Output
• Current Consumption: 120 VAC: 1.9 to 7 A; 240 VAC: 1 to 6.2 A

Physical

• Color: Black
• Mounting: Integrated Rigging
• Handles: 1x Each Side
• Construction Material: Aluminum, Plywood, Polypropylene
• Environmental Resistance: No
• Dimensions: 28.2 x 20.5 x 12" / 716.3 x 520.7 x 304.8 mm
• Weight: 59 lb / 26.8 kg

Packaging Info

• Package Weight: 66 lb
• Box Dimensions (L x W x H): 32 x 25.25 x 17"
