Key Specifications

Speaker Configuration

1× 2-Way Loudspeaker

Number of Input Channels

3 (2× Mono, 1× Stereo)

Amplifier Power Rating

HF: 1× 7 W
LF: 1× 93 W
Total: 60 W RMS / 100 W Peak

HF Driver

1× 1″ (2.5 cm) Compression Driver

LF Driver

1× 6.5″ (16.5 cm) Woofer

Audio I/O

1× Combo XLR–1/4″ (Mic/Line)
1× Combo XLR–1/4″ (Mic/Line/Hi-Z)
1× 1/8″ (3.5 mm) TRS Aux In
1× XLR (Line Out)

USB I/O

No

Bluetooth

Bluetooth 5.0

Portable PA System

Amplifier Class

HF/LF: Class-D

Enclosure Type

Bass-Reflex

Signal Processing

Crossover: 1.8 kHz (High-Pass, Internal)
EQ: HF Shelf, LF Shelf
Effects: None

Performance

Frequency Range

70 Hz – 20 kHz

Maximum SPL

120 dB SPL (Peak)

Coverage Angle

90° H × 90° V

Input Sensitivity

1/4″ Line: -6 dBu
XLR Mic: -36 dBu

Maximum Input Level

Line: +20 dBu
Mic: -10 dBu (Balanced)

I/O Impedance

1/4″ Line: 5.4 kΩ
XLR Mic: 5.4 kΩ
Hi-Z: 1 MΩ
Aux 1/8″: 10 kΩ

Wireless Connectivity

Bluetooth Version

5.0 (A2DP Profile)

Frequency Band

2.402–2.48 GHz

Power Class / Transmitter Power

Class 1 / 9 dBm

Power

AC Input Power

100–240 VAC, 50/60 Hz

Power Supply Output

24 VDC (Included)

Power Consumption

10 W (Idle) / 30 W (1/8 Power)

Physical

Transport Options

Integrated Handle

Mounting

1× 3/8″-16 Threaded Mount (Bottom)

Cooling

Convection

Construction Material

Plastic

Dimensions

12.2 × 9.4 × 8.5″ (31 × 23.9 × 21.5 cm)

Weight

11.5 lb (5.2 kg)
