Key Specifications

Speaker Configuration

1 × 2-Way Loudspeaker with Subwoofer

Number of Input Channels

5 (3 × Mono, 1 × Stereo)

Amplifier Power Rating

HF: 500 W
LF: 600 W
Total: 1100 W Program

Amplifier Class

Class-D

Speakers

Enclosure Type

Bass-Reflex (Subwoofer)

HF Driver

10 × 1.5" (38.1 mm)

LF Driver

1 × 12" (30.48 cm) Woofer

Signal Processing

Crossover

240 Hz

EQ

1 × Contour

Effects

4 × Reverb

Dynamic Processing

Compression, Peak Limiter

Performance

Frequency Response

37 Hz – 20 kHz (-10 dB)

Maximum SPL

125 dB SPL (Peak)

Coverage Angle

170° H × 30° V

Connectivity

Audio I/O

3 × Combo XLR-1/4" TRS Female (Mic/Line/Hi-Z)
2 × 1/4" TS Female (Line Input)
1 × 1/4" TRS Female (Footswitch Input)
1 × XLR 3-Pin Male (Balanced Link Input)
2 × XLR 3-Pin Female (Balanced Line/Link Output)

Wireless Connectivity

Bluetooth 5.0 (A2DP 1.2)

Bluetooth Range / Band

2.402 – 2.48 GHz, Power Class 1, 32 mW Output

Power

AC Input Power

110–120 VAC, 60 Hz / 220–240 VAC, 50/60 Hz

Power Consumption

25 W (Idle), 91 W (1/8 Power)

AC Power I/O

1 × IEC Input

Physical

Construction Material

ABS

Transport Options

1 × Top Handle

Dimensions (Full System)

78.74 × 16.46 × 13.15" (2000 × 418 × 334 mm)

Subwoofer Dimensions

21.65 × 16.46 × 13.15" (550 × 418 × 334 mm)

Speaker Dimensions

22.91 × 3.39 × 2.64" (582 × 86 × 67 mm)

Weight (Full Assembly)

50.71 lb (23 kg)

Subwoofer Weight

44.09 lb (20 kg)

Packaging Info

62.5 lb / 29.88 × 24.25 × 17"
