Key Specifications

Speaker Configuration

2× 2-Way Loudspeaker

Number of Input Channels

8

Amplifier Power Rating

400 W Peak (at 4 Ohms)
360 W RMS (at 4 Ohms)

HF Driver

1" (25.4 mm) Compression Driver

LF Driver

8" (20 cm) Woofer

Audio I/O

2× XLR 3-Pin Mic/Line Input
1× Combo XLR-1/4" TRS Mic/Line Input
1× Combo XLR-1/4" TRS Mic/Line/Hi-Z Input
4× 1/4" TRS Line Input
1× Stereo RCA Coaxial Line Input
1× 1/8" (3.5 mm) TRS Line Input
2× 1/4" TS Speaker Output
2× 1/4" TRS Monitor Output
1× 1/4" TRS Subwoofer Output
1× 1/4" TRS Footswitch Input

Bluetooth

Version 4.1

Speaker System

Enclosure Type

Bass-Reflex

HF Voice Coil

1" (2.54 cm)

Signal Processing

EQ

LF Shelf at 100 Hz

Effects

Reverb

Performance

Frequency Range

55 Hz – 20 kHz (-10 dB)

Maximum SPL

125 dB SPL

Coverage Angle

90° H × 60° V

Connectivity

Phantom Power

+30 V

Wireless Connectivity

Bluetooth 4.1 (A2DP 1.2, Manual Pairing, 32.8 ft / 10 m Range)

Power

AC Input Power

100 – 240 VAC, 50 / 60 Hz

Power Consumption

30 W (Idle), 70 W (1/8 Power)

AC Power I/O

IEC

Physical

Transport Options

Handle (Top)

Mounting

1× 1.4" / 35 mm Pole Socket

Environmental Resistance

No

Dimensions (W × H × D)

Speaker: 11.4 × 18.6 × 10.8" (28.9 × 47.2 × 27.5 cm)
Mixer: 12.1 × 7.1 × 4.6" (30.8 × 18 × 11.6 cm)

Weight

40.3 lb / 18.3 kg

Packaging Info

Package Weight: 49.75 lb
Box Dimensions (L × W × H): 26.5 × 22 × 14.9"
