Key Specifications

Speaker Configuration

2× 2-Way Loudspeaker

Number of Input Channels

10

Amplifier Power Rating

680 W Peak (at 4 Ohms)
560 W RMS (at 4 Ohms)

HF Driver

1.4" (35.6 mm) Compression Driver

LF Driver

10" (25 cm) Woofer

Audio I/O

2× XLR 3-Pin Mic/Line Input
1× Combo XLR-1/4" TRS Mic/Line Input
1× Combo XLR-1/4" TRS Mic/Line/Hi-Z Input
6× 1/4" TRS Line Input
1× Stereo RCA Coaxial Line Input
1× 1/8" (3.5 mm) TRS Line Input
2× 1/4" TS Speaker Output
2× 1/4" TRS Monitor Output
1× 1/4" TRS Subwoofer Output
1× 1/4" TRS Footswitch Input

Bluetooth

Version 4.1

Speaker System

Enclosure Type

Bass-Reflex

HF Voice Coil

1.4" (3.56 cm)

LF Voice Coil

—

Signal Processing

EQ

LF Shelf at 100 Hz
MF Peak at 2.5 kHz

Effects

Reverb

Performance

Frequency Range

55 Hz – 20 kHz (-10 dB)

Maximum SPL

129 dB SPL

Coverage Angle

90° H × 60° V

Connectivity

Phantom Power

+30 V

Wireless Connectivity

Bluetooth 4.1 (A2DP 1.2, Manual Pairing, 32.8 ft / 10 m Range)

Power

AC Input Power

100 – 240 VAC, 50 / 60 Hz

Power Consumption

35 W (Idle), 100 W (1/8 Power)

AC Power I/O

IEC

Physical

Transport Options

Handle (Top)

Mounting

1× 1.4" / 35 mm Pole Socket

Environmental Resistance

No

Dimensions (W × H × D)

Speaker: 13.2 × 21.5 × 12.6" (33.5 × 54.5 × 31.9 cm)
Mixer: 13.7 × 7.8 × 5.3" (34.8 × 19.7 × 13.5 cm)

Weight

56.4 lb / 25.6 kg

Packaging Info

Package Weight: 68.3 lb
Box Dimensions (L × W × H): 30 × 24.8 × 16.5"
