Key Specifications

Transducer

Pressure Gradient, JFET impedance converter

Polar Pattern

XY Cardioid (Coincident)

Frequency Range

40 ~ 20,000 Hz (selectable HPF @ 75 Hz)

Output Impedance

200 Ohms

Maximum Output

+4.2 dBu (@ 1% THD into 1 kOhms)

Power Supply

9 V alkaline battery

Connection

1/8" (3.5 mm) stereo mini-jack

Maximum SPL

134 dB, max (1 kHz, 1% THD into 1 kOhms)

Sensitivity

-38 dB re 1V/P (12.6 mV @ 94 dB SPL) ±2 dB @ 1 kHz

EIN

20 dBA SPL (A-weighted per IEC651)

Dynamic Range

100 dB (per IEC651)

Signal to Noise Ratio

73 dB SPL (A-weighted per IEC651)

Dimensions

2.6 × 4.25 × 5.1" / 66 × 108 × 130 mm

Weight

4.1 oz / 117 g (without battery)

Packaging Information

Package Weight

0.55 lb

Box Dimensions (L × W × H)

7.3 × 6.4 × 3"
