Key Specifications

Channels of I/O

Analog: 8 Inputs / 6 Outputs at 192 kHz
Digital: 10 Inputs / 2 Outputs at 48 kHz

Maximum Sampling Rate

192 kHz / 24-Bit

Number of Microphone Inputs

4 Preamps

Analog Audio I/O

2x Combo XLR-1/4" TRS Mic/Line/Hi-Z Input
2x Combo XLR-1/4" TRS Mic/Line Input
4x 1/4" TRS Line Input
6x 1/4" TRS Line Output
2x 1/4" TRS Headphone Output

Digital Audio I/O

1x ADAT Input
1x S/PDIF Input
1x S/PDIF Output

Host Connection

1x USB-C (Class-Compliant, USB 2.0)

OS Compatibility

macOS 10.13+, Windows 10+, iOS/Android via USB-C

Phantom Power

48 V, Selectable On/Off (All Inputs)

Frequency Response

20 Hz – 20 kHz (Mic/Line/Hi-Z/Monitor/Line/Headphone)

THD + N

Mic/Line: 0.005%, Hi-Z: 0.02%, Line/Monitor: 0.004%, Headphones: 0.25%

Dynamic Range

AD/DA Converters: 114 dB
Mic Inputs: 110 dBA
Line/Hi-Z Inputs: 112 dBA
Monitor Outputs: 108 dBA
Headphone Outputs: 103 dBA

Dimensions (HxWxD)

31.8 × 14 × 4.45 cm / 12.5 × 5.5 × 1.75"

Net Weight

1.5 kg / 3.2 lb

Package Weight

5.38 lb

Box Dimensions (LxWxH)

20.2 × 10.1 × 10.1"
