Key Specifications

Channels of I/O

Analog: 2 Inputs / 2 Outputs at 192 kHz

Maximum Sampling Rate

192 kHz / 24-Bit

Microphone Inputs

2

Analog Audio I/O

2x Combo XLR-1/4" TRS Mic/Line/Hi-Z Input
2x 1/4" TRS Line/Monitor Output
1x 1/4" TRS Headphone Output

Digital Audio I/O

No

Host Connection

1x USB-C (Class-Compliant)

Power Requirements

USB Bus Power

Display

4x Multi-Segment LED Meter

Built-In DSP

No

Input Level Adjustment

2x Knob

Gain / Trim Range

Inputs: 50 dB

Phantom Power

48 V, Selectable On/Off (Applied to All Inputs)

MIDI I/O

1x DIN 5-Pin Input / 1x DIN 5-Pin Output

Frequency Response

Mic Inputs: 20 Hz – 20 kHz ±0.3 dB
Hi-Z Inputs: 20 Hz – 20 kHz ±0.1 dB
Monitor Outputs: 20 Hz – 20 kHz ±0.3 dB
Headphone Outputs: 20 Hz – 20 kHz ±0.5 dB

Maximum Input Level

Mic Inputs: +10 dBu
Hi-Z Inputs: +19 dBu

Maximum Output Level

Monitor Outputs: +10 dBu (Balanced)

Headphone Output Power

47 mW per Channel into 56 Ohms

Impedance

Mic Inputs: 1.4 kΩ
Hi-Z Inputs: 750 kΩ
Headphone Outputs: 32 – 300 Ω

Dynamic Range

Mic Inputs: 106 dBA
Hi-Z Inputs: 105 dBA
Monitor Outputs: 104 dB
Headphone Outputs: 83 dBA
AD/DA Converters: 108 dB

THD+N

Mic Inputs: 0.004%
Hi-Z Inputs: 0.002%
Monitor Outputs: 0.001%
Headphone Outputs: 0.01%

EIN

-126 dBu A-Weighted

Compatibility

macOS 10.13 or Later / Windows 10 or Later

Dimensions (HxWxD)

7 × 5.5 × 1.75" / 17.8 × 14 × 4.45 cm

Net Weight

2.0 lb / 0.9 kg

Package Weight

2.285 lb

Box Dimensions (LxWxH)

7.8 × 7.5 × 2"
