Key Specifications

Lens Mount

Micro Four Thirds

Image Sensor

17.78 x 10 mm (Four Thirds) CMOS

ISO/Gain Sensitivity

Native: 100 to 25,600 | Gain: 0 to 18 dB

Internal Recording (Blackmagic RAW 10-Bit)

3840 x 2160 at up to 60 fps [26 to 190 Mb/s]

Video Output

SDI/BNC / HDMI (3840x2160, 1920x1080p)

Video I/O

• 1x BNC (12G-SDI) Input
• 1x BNC (12G-SDI) Output
• 1x HDMI Output

Battery

Built-In Lithium-Ion

Imaging

Lens Mount

Micro Four Thirds

Image Sensor

17.78 x 10 mm (Four Thirds) CMOS

Sensor Resolution

Not Specified by Manufacturer

Exposure Control

Shutter Speed

1/5000 to 1/24 Second

Signal-to-Noise Ratio

63 dB

Sensitivity

f/11 at 2000 lux (UHD 4K60)

Video Capture

Internal Recording (Blackmagic RAW 10-Bit)

3840 x 2160 at up to 60 fps

Broadcast Output

NTSC, PAL

Built-In Microphone

Stereo

Audio Recording

Raw: 2-Channel, 24-Bit at 48 kHz via LPCM Audio

Interface

Media/Memory Card Slot

No

CCU I/O

1x RJ45 (for optional Fibre Adapter)

Video I/O

• 1x BNC (12G-SDI) Input
• 1x BNC (12G-SDI) Output
• 1x HDMI Output

Audio I/O

• 2x XLR 3-Pin Mic/Line Input (+48 V Phantom Power)
• 1x 1/8" / 3.5 mm TRRS Headphone/Mic Input/Output
• 1x 1/8" / 3.5 mm TRS Stereo Microphone Input
• 1x XLR 5-Pin Intercom Input/Output

Power I/O

• 1x XLR 4-Pin (12VDC) Input
• 1x Barrel (12VDC) Input

Other I/O

• 1x RJ45 (10 Gigabit Ethernet) Monitor/Video/Data/Control Input/Output
• 2x USB-C (USB 3.2 / 3.1 Gen 1) Video/Data Input/Output

Monitor

Display Type

Fixed Touchscreen LCD

Resolution

1920 x 1200

Power

Power Consumption

46 W

General

Tripod Mount

3/8"-16 Female

Dimensions (W x H x D)

10.77 x 6.68 x 6.59" / 27.36 x 16.97 x 16.74 cm (Without Protrusions)

Weight

3.71 lb / 1.68 kg (Body Only)

Packaging Info

Package Weight

7.59 lb

Box Dimensions (L x W x H)

12.2 x 10.2 x 8.3"
