Key Specifications

Performance

• Frequency Response: 35 Hz - 120 Hz
• Max SPL @ 1m: 133 dB

Transducers

• Woofer: 1 x 18'', 3.0'' v.c.

Processor & Power Section

Amplification

• Total Power: 1400 W Peak / 700 W RMS
• Cooling: Convection
• Protections: Thermal, RMS
• Limiter: Soft Limiter

DSP & Controls

• Crossover: 80 Hz (LPF) / 110 Hz (HPF)
• Controls: Volume, EQ, Phase, Xover

Input / Output Section

• Connectors: XLR In, XLR Out
• Signal: Balanced / Unbalanced
• Sensitivity: -2 dBu / +4 dBu
• Power: VDE

Physical Specifications

Construction

• Cabinet: Baltic Birch Plywood
• Hardware: M20 pole mount thread
• Handles: One per side
• Grille: Steel with clothing
• Color: Black
• Compliance: CE compliant

Size / Weight

• Dimensions: 27.28 x 19.88 x 26.97" / 693 x 505 x 685 mm
• Weight: 89.51 lbs / 40.6 kg

Packaging Info

• Package Weight: 100.53 lbs / 45.6 kg
• Box Dimensions: 28.94 x 22.24 x 29.33" / 735 x 565 x 745 mm
