Key Specifications

Frequency Range / Response

25 Hz to 200 Hz

Speaker Type

Active Subwoofer

Enclosure Type

Bass-Reflex

Total Output Power

8000 W Peak

Amplifier Class

Class-D

Drivers

LF Driver

2x 19" / 48.26 cm Inverted Woofer

Voice Coil

4" / 101.6 mm

Performance

Frequency Range / Response

25 Hz to 200 Hz

Maximum SPL

142 dB

Protections

RMS, Thermal

Signal Processing

EQ & Filters

Preset EQ Curves

Dynamic Processing

Soft Limiter

Alignment Delay

Yes (Delay Time/Distance Unspecified)

Digital Signal Processing

Delay, Venue Settings

Connectivity

Audio I/O

1x XLR 3-Pin Line Input
1x XLR 3-Pin Link Output
1x XLR 3-Pin High-Pass Output

Network I/O

2x etherCON/RJ45 (RDNet)

USB I/O

No

Wireless

No

Mobile App Compatible

Yes (Android & iOS)

App Name

RDTap

App Functionality

Adjust Settings, Firmware Update, Setup

Power

AC Input Power

100 to 240 VAC, 50 / 60 Hz

AC Power I/O

1x powerCON Input
1x powerCON Output

Physical

Color

Black

Mounting

1 x M20-Threaded Pole Socket (Top)

Handles

3x Each Side

Construction Material

Plywood, Steel

Environmental Resistance

No

Dimensions

51.5 x 30.9 x 21" / 130.8 x 78.5 x 53.3 cm

Weight

451.9 lb / 205 kg
