Key Specifications

Video & Audio I/O

SDI Video Input

1x SDI on BNC 12G-SDI (SD/HD/2K/4K auto switching)

HDMI Output

1x HDMI 2.0 type A

Analog Audio Output

2 channels balanced analog audio via XLR (Right XLR can be timecode)

AES/EBU Audio Output

4 channels 110 ohm balanced digital audio via XLR (Right XLR can be timecode)

Optical Fiber Support

Supports optional optical fiber module

SDI & HDMI Standards

Multi Rate Support

Automatic switching between SD, HD, 2K, and 4K

Re-Clocking

Yes

SDI Video Rates

Auto switching (SD-SDI up to 12G-SDI)

SDI Compliance

SMPTE 292M, 425M, 297M (for Optical Fiber SDI) and others

SDI/HDMI Color Space

YUV, RGB (SDI); REC 601, REC 709 (HDMI)

SDI/HDMI Color Precision

4:2:2 and 4:4:4

Supported Formats

SD Format Support

525/29.97 NTSC, 625/25 PAL (SDI & HDMI)

HD Format Support

720p, 1080i, 1080p/PsF (up to 60 fps) (SDI & HDMI)

2K Format Support

2048 x 1080p/PsF (up to 25 fps) (SDI & HDMI)

4K Format Support

3840 x 2160p and 4096 x 2160p (up to 60 fps) (SDI & HDMI)

Control & Power

Updates and Configuration

USB or Ethernet

Power Supply

Built-in international AC supply (90 - 240 VAC)

Power Over Ethernet (PoE)

Can be powered via 48 VDC using PoE

Power Consumption

15 W

Environmental & Physical

Operating Temperature

32 to 104°F (0 to 40°C)

Dimensions (W x H x D)

5.5 x 1.8 x 6.7" (14 x 4.6 x 17 cm)

Weight

1.3 lb (0.6 kg)

Packaging Info

Package Weight

1.825 lb

Box Dimensions (L x W x H)

10.8 x 7.6 x 2.6"
