MACKIE Thrash215
MACKIE Thrash215
|
Key Specifications |
|
|
Speaker Configuration |
1x 2-Way Loudspeaker |
|
Number of Input Channels |
2 (2 x Mono) |
|
Amplifier Power Rating |
Total: 1300 W Peak |
|
HF Driver |
1x 1" / 25.4 mm Titanium Compression Driver |
|
LF Driver |
1x 15" / 381 mm Woofer |
|
Audio I/O |
Combo XLR-1/4" / XLR |
|
USB I/O |
No |
|
Wireless |
No |
|
Portable PA System |
|
|
Speaker Configuration |
1x 2-Way Loudspeaker |
|
Number of Input Channels |
2 (2 x Mono) |
|
Amplifier Power Rating |
Total: 1300 W Peak |
|
Amplifier Class |
Class-D |
|
Speakers |
|
|
Enclosure Type |
Bass-Reflex |
|
HF Driver |
1x 1" / 25.4 mm Titanium Compression Driver |
|
LF Driver |
1x 15" / 381 mm Woofer |
|
Magnet |
LF Driver: Ferrite |
|
Signal Processing |
|
|
Crossover |
2.4 kHz, 24 dB/Octave |
|
EQ |
No |
|
Semi-Parametric EQ |
No |
|
Effects |
No |
|
Filters |
No |
|
Dynamic Processing |
Peak Limiter |
|
Performance |
|
|
Frequency Response |
55 Hz to 20 kHz (-3 dB) |
|
Frequency Range |
38 Hz to 20 kHz (-10 dB) |
|
Maximum SPL |
126 dB |
|
Coverage Angle |
90° H x 60° V |
|
I/O Impedance |
XLR Mic Input: 20 Kilohms (Balanced) |
|
Protections |
Output Limiter, Power Supply, RMS, Thermal |
|
Connectivity |
|
|
Audio I/O |
2x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line/Hi-Z Input |
|
USB I/O |
No |
|
Network I/O |
No |
|
Wireless |
|
|
Wireless |
No |
|
Power |
|
|
AC Input Power |
100 to 240 VAC, 50 / 60 Hz |
|
Power Consumption |
75 W |
|
AC Power I/O |
1x IEC Input |
|
Physical |
|
|
Transport Options |
4x Handle |
|
Mounting |
1 x Pole Socket (Bottom) |
|
Construction Material |
Metal Grille, Polypropylene |
|
Dimensions |
28 x 17.1 x 14.3" / 711.2 x 434.3 x 363.2 mm |
|
Weight |
40.8 lb / 18.5 kg |
|
Packaging Info |
|
|
Package Weight |
44.1 lb |
|
Box Dimensions (L × W × H) |
30.5 x 19 x 16.5" |
