Key Specifications

Active or Passive

Active

System Type

Full-Range

Configuration

2-way

System Continuous Power

180 W

System Peak Power

360 W

Max SPL @ 1m

124 dB

Freq Range (-10 dB)

65 Hz - 20 KHz

Freq Response (+/-3 dB)

70 Hz - 20 KHz

Bi-amp Mode Switch

No

Bluetooth

No

IP Certification

IP54

Driver Brand

Wharfedale Pro

LF Driver Size

8"

LF Voice Coil Size

1.53"

LF Rated Impedance

4 Ω

LF Power (RE:AES2-2012)

150 W

HF Driver Type

Compression Driver

HF Voice Coil Size

1"

HF Diaphragm Material

Mylar

HF Exit Size

1.2"

HF Power (RE:AES2-2012)

20 W

HF Rated Impedance

8 Ω

HF Nominal Coverage (H x V)

Elliptical waveguide 90° x 60°

Preset Library

No

Input Connector

1/4” jack / XLR combo

Waveguide Type

Elliptical

Enclosure Material

Polypropylene

Grille Material and Finish

Steel

Finish

Grey, White or Black

Handles

1

Deployment

Flying, Pole, Wall Mount, Ground

Pole Mount

35 mm With Lock Screw

Brackets Included

No

Rigging

Yes

M6

8

Sensitivity 2.83v / 1m

n/a dB

System Rated Impedance

n/a

Recommended HPF = BW 18 dB/OCT.

65 Hz

Transformer (T)

No

Transformer Taps (70 V)

No

Transformer Taps (100 V)

No

Input Connectors (T)

No

Amplifier design

Class D

EQ Type

High (±10 dB) 10 KHz Shelving
Low (±10 dB) 100 Hz Shelving

Link Connector

Pin XLR

Line Output

Switchable LOOP/MIX Balanced socket XLR

Main Power

AC100-120 V~ / 220-240 V~, 50/60 Hz

Power Supply

SMPS

Included Accessory

User Manual, AC Cable

Unpacked - Height (mm)

396

Unpacked - Width Front (mm)

266

Unpacked - Width Rear (mm)

266

Unpacked - Depth (mm)

221

Packed - Height (mm)

463

Packed - Width Front (mm)

325

Packed - Width Rear (mm)

325

Packed - Depth (mm)

282

Weight - Nett (kg)

6.25

Weight - Gross (kg)

8.75
